Compatible FM4428 Cards

Compatible FM4428 Cards

  • Available chips: SLE4442,SLE4428,AT24C01, AT24C02, AT24C16,AT24C64etc.
  • Size: ISO standard 85.6x54mm
  • Crafts: Embossing and tipping, thermal printing of serial numbers and name,Scratch-off
  • Memory:1024x8 bit EEPROM
SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

  • PRODUCT DETAIL

Compatible FM4428 Cards

Features
– Byte-wise write protection of Data Memory (one time programmable)
– Not alterable Manufacturer Code (chip coding and unique coding by application identifier
RID according to ISO/IEC 7816-5)
• Data Memory alterable only after verification of 2 Byte PSC
• PSC verification trials limited by Error Counter
• Serial synchronous three-wire link protocol according to ISO/IEC 7816
– Byte-wise addressing
– End of processing indicated at data output
• Contact configuration and Answer-to-Reset (synchronous transmission) in accordance
to standard ISO/IEC 7816
• Electrical characteristics
– Ambient temperature range -40 … +100°C for chip, -25 … +80°C for module
– Supply voltage 5V ± 10%
– Supply current < 1 mA
– EEPROM erase / write time 5 ms / 5 ms
– ESD protection typically 4,000 V
– EEPROM Endurance minimum 100,000 erase / write cycles
